The Synchro Resolver Guide introduces the operation of synchro resolvers and selsyns, and provides detailed information on how to convert synchro resolver signals to dc voltage or frequency
The MT-030 resolver‑to‑digital converter (RDC) provides precise angle and rotation information for applications requiring small size, long‑term reliability and high accuracy. It explains the differences between self‑aligning resolvers and traditional resolvers, and describes how the RDC processes signals to produce digital angle outputs.
The document details the signal processing chain, error amplification, detection, and tracking ADC implementation, and includes reference information for the AD2S90 family of integrated RDCs. It also lists typical electrical specifications and performance characteristics. This manual is written in Chinese.
| Input voltage range | 2 V to 40 V rms |
|---|---|
| Operating frequency range | 400 Hz to 10 kHz |
| Angle accuracy | 5 to 0.5 arc‑minutes |
The resolver is rated for an input voltage of 2 V to 40 V rms.
It operates over a frequency range of 400 Hz to 10 kHz.
The angle accuracy is specified as 5 to 0.5 arc‑minutes.
