The advanced hybrid system KX-TA30 is capable of receiving caller identification information and displaying it on compatible phones. It supports caller identification services provided by the telephone company and allows users to view the caller's information, such as name and phone number. The system also features call logging and easy callback functionality.
The manual provides step‑by‑step instructions for installing the Caller ID information delivery and display card into a KX‑TA30 system, including wiring, grounding, and securing the unit. It also describes system functions such as providing caller name and number to compatible display phones (KX‑T7030 or KX‑T7130) and the requirements for service activation with the telephone company.
Programming sections cover setting up line codes, area codes, and adjustments for local and long‑distance calls, as well as configuring SMDR format, priority of displayed information, and key assignments on the functional phones. Example displays and troubleshooting tips are included to help users verify correct operation. This manual is written in Chinese.
| External lines supported per card | 3 lines (CO) |
|---|---|
| Maximum stored calls per extension | 20 calls |
| Caller number digits displayed during call | First 16 digits |
| Recorded caller info digits displayed | First 13 digits |
Each Caller ID information delivery and display card supports up to three external lines (CO).
Each extension can store up to 20 call records.
Only the first 16 digits of the caller's number are displayed on the LCD.
Use program [904] "主叫识别信息记录优先选择" to choose whether the initial display shows the number, the name, or both.
