Instruction manual, introducing the features of MBPS, usage methods, precautions, etc.
This manual outlines safety precautions for the NBK MBPS linear guide, including limits on holding force, avoiding slip caused by lubrication or low air pressure, and the need for protective covers and proper torque tools. It stresses that improper operation can cause injury, equipment damage, or even fatal accidents, and advises users to disconnect power before installation or maintenance.
Installation steps are detailed, from confirming free movement of the guide without contact, pre‑tightening on the slide, clamping, applying the specified tightening torque, and verifying smooth movement. The document also provides torque values, pressure ranges, and contact information for the NBK customer center. This manual is written in Chinese.
| Operating Pressure Range | 0.45 MPa – 0.8 MPa |
|---|---|
| Maximum Pressure | 0.06 MPa |
