Aolynk S1505L is a smart Ethernet switch suitable for small and medium-sized enterprises and home networking.
The manual introduces the Aolynk S1505L Intelligent Ethernet Switch, a 5‑port 10/100Base‑TX device designed for small‑business and home networking. It describes the front and rear panel LEDs, port functions (Uplink, VoIP, TV, PC, EXP), and key features such as VLAN support, QoS, and storm control.
Installation steps cover hardware setup, power adapter connection, and USB driver installation for PC configuration. Configuration chapters detail login, basic and advanced settings, and the technical specifications appendix lists all electrical and environmental parameters. This manual is written in Chinese.
| Fixed ports | 5 × 10/100Base‑TX adaptive Ethernet ports |
|---|---|
| Connector type | RJ‑45 |
| Port speed | 10/100 Mbits |
| Duplex modes | Half‑duplex, full‑duplex, auto‑negotiation |
| Dimensions | 150 mm × 110 mm × 34 mm |
| Weight | 300 g |
| Input voltage | 9 V AC |
| Operating temperature | 0 °C – 40 °C |
| Storage temperature | -10 °C – 70 °C |
The S1505L provides five fixed 10/100Base‑TX adaptive Ethernet ports.
The device requires a 9 V AC power input.
The switch operates between 0 °C and 40 °C.
