This manual covers the Panasonic NR‑B21S6 household refrigerator, describing its features such as a top‑freezer layout, steel‑glass shelves, and a dedicated freezer compartment for organized storage. It also includes the warranty card and contact information for service.
The document is organized into sections on safety precautions, installation requirements, moving and transport, compartment usage, a packing list, and detailed technical specifications. It provides clear diagrams and step‑by‑step instructions to help users set up and operate the appliance safely and efficiently. This manual is written in Chinese.
| Total capacity | 212 L |
|---|---|
| Refrigerator compartment capacity | 142 L |
| Freezer compartment capacity | 70 L |
| Rated voltage | 220 V |
| Rated frequency | 50 Hz |
| Ice making capacity | 1.4 kg/24 h |
| Freezing capacity | 4.0 kg/24 h |
| Rated current | 0.85 A |
| Power consumption | 0.60 kWh/24 h |
| Energy efficiency class | 1 |
| Refrigerant | R600a 55 g |
| Noise level | 38 dB(A) |
| Weight | 54 kg |
| Dimensions (W×D×H) | 550 × 633 × 1530 mm |
Leave at least 4 cm on the left and right sides and at least 10 cm at the back and top of the unit.
Do not use a damaged power plug or a loose socket, keep the appliance away from heat sources, do not place flammable items inside, and ensure the power circuit is properly grounded.
The refrigerator provides a total usable volume of 212 L (142 L for fresh food and 70 L for frozen food).
It is rated for 220 V and 50 Hz mains supply.
