This document is a user manual for a DVR (Digital Video Recorder), which introduces the functions, features, and usage of the DVR.
This manual provides detailed instructions for installing, configuring and operating the 16‑channel D9016H digital video recorder. It includes safety precautions, hardware connections, menu navigation, client software usage, and maintenance guidelines.
The document is organized into chapters covering the device overview, front and rear panel descriptions, hardware connections, system startup, menu functions, client software, technical specifications, and an appendix with quick‑reference tables and FAQs. This manual is written in Chinese.
| Model | D9016H |
|---|---|
| Channels | 16 video inputs / 2 video outputs |
| Video Input | CH1‑16 analog BNC connectors |
| Video Output | Main video output (BNC) |
| Audio Input | CH1‑4 BNC connectors |
| Audio Output | BNC audio output |
| Network Interface | RJ45 10/100 Mbps Ethernet |
| HDMI Interface | HDMI high‑definition output |
| VGA Interface | VGA video output |
| Power Adapter | DC 12 V 5 A |
| Power Consumption | 10‑15 W (without hard drive) |
| Dimensions | 430 × 380 × 70 mm (L×W×H) |
| Operating Temperature | 10 °C ~ +40 °C |
| Storage Interface | SATA hard‑drive support, USB external storage |
Check that the hard‑drive data and power cables are securely connected and that the drive is compatible with the system.
Verify that the BNC video cables are properly connected, not damaged, and that the NTSC/PAL mode matches the camera.
Yes, the system supports simultaneous recording and playback.
The STOP button only stops manual recording; to stop timed or continuous recording you must change the recording mode in the settings.
