This document provides specifications and configurations of the VGN-SR1 series products, including operating system, processor, hard drive, memory, LCD display, graphics processor, sound performance, etc.
The Sony VGN‑SR1 series notebook is offered with Intel® Core2 Duo dual‑core processors (P8600 or P8400) and DDR2 memory options up to 2 GB. Storage capacities range from 160 GB to 250 GB Serial ATA drives, and the 13.3‑inch WXGA (1280 × 800) LED‑backlit display is paired with an ATI Mobility Radeon HD 3470 graphics chip with 128 MB GDDR3.
Connectivity includes Ethernet (100BASE‑TX/10BASE‑T), dual USB 2.0 ports, VGA, ExpressCard/34, and optional Wi‑Fi (IEEE 802.11a/b/g/n). The notebook features built‑in stereo speakers, microphone, a DVD‑R/W optical drive, and a lithium‑ion battery providing up to 45 hours of operation under test conditions. This manual is written in Chinese.
| Processor | Intel® Core2 Duo P8600 (2.40 GHz) or P8400 (2.26 GHz) |
|---|---|
| Memory | 1 GB DDR2 (PC2‑6400 ‑ DDR2‑800) up to 2 GB |
| Storage | 250 GB Serial ATA 5400 RPM (or 160 GB option) |
| Display | 13.3‑inch WXGA (1280 × 800) TFT LED |
| Graphics | ATI Mobility Radeon HD 3470 with 128 MB GDDR3 |
| Optical Drive | DVD‑R/W, 24× CD‑ROM, 8× DVD‑ROM |
It provides two high‑speed USB 2.0 ports.
Install identical capacity DDR2 modules in both slots to enable dual‑channel mode.
