The Philips Immersive Sound Home Theater 3D Point Source Speaker 3D Blu-ray HTS5590 is a home theater that uses 3D point source speakers to deliver a true cinematic audio experience, and supports Blu-ray disc playback.
The HTS5590 is a Philips home‑theater 3D speaker system that uses 3D‑point speaker technology to spread sound evenly throughout a room, delivering up to 1000 W RMS power, Dolby TrueHD and DTS‑HD Master Audio, and DoubleBass low‑frequency enhancement. It supports full‑HD 3D Blu‑ray playback and a wide range of media formats.
This manual outlines the product’s key features, detailed technical specifications, and all available audio/video and connectivity options such as HDMI ARC, USB, MP3 input, FM antenna, LAN and wireless rear speakers. It also lists the included accessories and provides guidance for setup, operation, and troubleshooting. This manual is written in Chinese.
| Total RMS Power | 1000 W |
|---|---|
| Frequency Response | 20 – 20000 Hz |
| Signal‑to‑Noise Ratio | > 65 dB |
| Audio System | Dolby TrueHD, DTS‑HD Master Audio, DTS, Dolby Logic II, Stereo, DTS‑96/24, Dolby Digital 5.1 |
| Audio Enhancement | DoubleBass, FullSound, Night Mode, Bass/Treble Control, Dialogue Boost |
| Video Playback Formats | DivX Ultra, MPEG‑1/2/4, WMV, AVCHD, XviD, MKV |
| Audio Playback Formats | MP3, WMA, PCM |
| Standby Power Consumption | < 0.9 W |
| Power Input | 220‑240 V, 50 Hz |
| Dimensions (W×H×D) | 435 × 58 × 358 mm |
| Weight (incl. packaging) | 33.3 kg |
The system delivers a total RMS power of 1000 W.
It supports Dolby TrueHD, DTS‑HD Master Audio, DTS, Dolby Logic II, Stereo, DTS‑96/24, and Dolby Digital 5.1.
