Miller's PRO Series leads the industry in performance and value. These diesel powered engine drives have excellent arc performance for all types of welding jobs, especially for cross-country pipeline welders and any professional welder who needs exceptional arc performance.
The TrailblazerPro 350 and PipePro 304 are diesel‑powered welding machines designed for professional and pipe‑line welders. They feature a 26 HP, 3‑cylinder Kubota engine, 12,000 W peak AC auxiliary power, and a compact, lightweight design that reduces transportation costs.
Both models provide multi‑process capability (Stick, MIG, FCAW, TIG) with a patented Arc Drive and Weld‑at‑Idle technology that improves arc stability while lowering fuel consumption and emissions. The machines also include tool‑less engine access, remote oil drain, and voltage‑regulated auxiliary power for reliable operation of job‑site tools.
| Engine Power | 26 HP |
|---|---|
| Auxiliary Power (peak) | 12,000 W |
| Fuel Consumption (40% duty, 150 A) | 0.9 gallons per hour |
| Weight (TrailblazerPro 350) | 1,029 lb (467 kg) |
| Weight (PipePro 304) | 910 lb (412 kg) |
| Weld‑at‑Idle Power | up to 5 kW (225 A @ 23 V, 170 A @ 30 V) |
It uses a 26 HP, 3‑cylinder Kubota diesel engine.
The machine provides 12,000 W (peak) of voltage‑regulated AC auxiliary power.
Fuel consumption is 0.9 gallons per hour at 40 % duty cycle and 150 A weld output.
It weighs 1,029 lb (467 kg).
