The PRO series transmitters are manufactured using new technologies and materials, with significant improvements in circuitry, processes, and structure. They have higher measurement accuracy, more stable operation, stronger anti-interference capabilities, and better cost-effectiveness. The products comply with IEC688-1992 and GB/T 13850-1998 standards and are ISO9001-2000 certified.
This manual provides operating instructions, wiring diagrams, and technical specifications for the PRO series transmitters. It describes common features shared by all models and details the specific functions of each transmitter type.
Each section includes input voltage ranges, output ranges, frequency options, and connection methods. The final pages contain manufacturer contact information and compliance statements. This manual is written in Chinese.
| Input voltage range | 24‑60VAC/DC, 85‑230VAC/DC |
|---|---|
| Output voltage options | 0‑100V, 120V, 220V, 380V, 500V, 600V |
| Frequency | 50 Hz / 60 Hz |
| Output current range | 0‑1A, 2A, 5A |
| Phase angle measurement range | -60° to 60°, -90° to 90°, 0° to 180°, 0° to 270° |
It supports 24‑60VAC/DC or 85‑230VAC/DC.
Output voltage can be selected from 0‑100V, 120V, 220V, 380V, 500V, or 600V.
It measures phase angles from –60° to 60°, –90° to 90°, 0° to 180°, and 0° to 270°.
