This manual introduces the features and usage of the IBX-300BC embedded system.
This manual introduces the IEI IBX-300BC fan‑less embedded system, detailing its hardware architecture, component layout, and key features such as eight video inputs, four USB ports, RS‑232, VGA, and Gigabit Ethernet. It also lists the technical specifications, including the Intel® Atom™ D510 CPU and DDR2 memory.
The document guides users through mechanical installation, jumper configuration, BIOS setup, operating‑system installation, and the One‑Key Recovery process, while also covering safety precautions, connector pin‑outs, and hazardous‑material disclosures.
| Processor | Intel® Atom™ D510 CPU |
|---|---|
| Memory type | DDR2 |
| Video inputs | Eight channels |
| USB ports | Four USB |
| Compliance | RoHS compliant |
The AT Power Select jumper settings are described in section 3.3.2 of the manual.
The One‑Key Recovery procedure is introduced in section A.1 of the manual and provides a single‑press method to restore the system to factory defaults.
Section B outlines general safety and anti‑static precautions to prevent damage during installation and maintenance.
