This VPCEA22FX/P VAIO® E Series laptop has multimedia capabilities and an Intel® Core™ i3-350M processor and 4GB of memory.
This manual describes the Sony VAIO E Series laptop VPCEA22FX/P, detailing its hardware components such as the Intel Core i3‑350M processor, 4 GB of installed DDR3 memory (expandable to 8 GB), a 500 GB hard drive, and a 14‑inch LED‑backlit display with a 1366 × 768 resolution. It also lists the built‑in camera, audio system, and battery options.
Connectivity options include HDMI, VGA, four USB ports (one shared with eSATA), Ethernet, Wi‑Fi (Intel Centrino Advanced‑N 6200), and Bluetooth 2.1+EDR. The manual covers supported software, warranty information, and support services such as VAIO Care™ and on‑site assistance.
| Processor Speed | 2.26 GHz |
|---|---|
| L3 Cache | 3 MB |
| Installed RAM | 4 GB (2 × 2 GB) |
| Maximum RAM | 8 GB DDR3 1066 MHz |
| Hard Drive Capacity | 500 GB |
| Hard Drive Speed | 5400 rpm |
| Screen Size | 14 inches |
| Resolution | 1366 × 768 |
| Back Light Technology | LED |
| Weight | 6.2 lb |
| Dimensions | 13.6 W × 1.07 H × 9.39 D inches |
| USB Ports | 4 (one shared with eSATA) |
| Ethernet | 1 port, Fast Ethernet |
| Bluetooth | Integrated Sereo A2DP (2.1 + EDR) |
| HDMI Output | 1 port |
| Operating System | Microsoft Windows 7 Home Premium 64‑bit |
The laptop comes with 4 GB (2 × 2 GB) of DDR3 memory installed and can be expanded up to 8 GB.
It includes a 500 GB hard drive that spins at 5400 rpm and connects via Serial ATA.
The laptop provides 4 USB ports (one shared with eSATA), HDMI, VGA, Ethernet, Wi‑Fi (Intel Centrino Advanced‑N 6200), and Bluetooth 2.1 + EDR.
