Thunder K8SE /// S2892 is a desktop motherboard
This manual introduces the TYAN Thunder K8SE server/workstation motherboard, detailing its hardware and software specifications, supported processors, memory capacity, and integrated controllers. It also outlines the board’s form factor, power requirements, and regulatory compliance.
Installation instructions cover board placement, processor and memory installation, cable connections, and power‑supply setup, followed by BIOS configuration and diagnostic beep codes. Technical support information and warranty details are provided at the end of the document.
| Supported Processors | Up to two AMD Opteron (200 series) processors |
|---|---|
| Maximum Memory | 16 GB DDR400/333 Registered ECC |
| Chipset | Nvidia nForce pro2200 |
| SATA II Controllers | Two dual‑port SATA II controllers, four SATA connectors, up to 3 Gb/s |
| LAN Controllers | Broadcom BCM5704 Dual‑Port GbE and Intel 82551QM 10/100 Ethernet |
| Form Factor | SSI EEB v3.0 (12" × 13") |
| Power Supply Compatibility | SSI or EPS12V (24‑pin + 8‑pin); ATX 2.x not supported |
It supports up to two AMD Opteron (200 series) processors.
The board can handle up to 16 GB of DDR400/333 Registered ECC memory.
It requires an SSI or EPS12V power supply (24‑pin + 8‑pin) and cannot use ATX 2.x or ATXGES supplies.
The motherboard includes a Broadcom BCM5704 Dual‑Port Gigabit Ethernet controller and an Intel 82551QM 10/100 Ethernet controller.
