Prostar 6910 disk array is an extensible high-performance storage server suitable for high-demand data-intensive computing environments. It offers a storage capacity of 168TB and supports various configurations to meet different needs. It features excellent performance, secure and reliable design, and modular design.
The Prostar 6910 is an enterprise‑class 4 GB full‑fibre storage server offering up to 168 TB of capacity and high‑performance I/O for data‑intensive applications such as OLTP and data mining. It features dual active RAID controllers, optional cache up to 16 GB with battery backup, and hot‑swap redundant components for maximum availability.
The included SANtricity management software provides unified control, online expansion, and data protection features like DAC storage technology. The system supports a wide range of operating systems and can be expanded to 224 drives across 14 enclosures, delivering up to 575 000 IOPS and 1.7 GB/s cache throughput. This manual is written in Chinese.
| Maximum storage capacity | 168 TB |
|---|---|
| Supported RAID levels | 0, 1, 3, 5, 10 |
| Controller cache size | 2/4/8/16 GB (optional, battery‑backed) |
| Host interfaces | 8 × 4 Gbps Fibre Channel |
| Disk interfaces | 8 × 4 Gbps Fibre Channel |
| Maximum IOPS (cache) | 575 000 IOPS |
| Maximum sustained I/O (disk) | 86 000 IOPS |
| Maximum transfer rate (cache) | 1.7 GB/s |
| Maximum transfer rate (disk) | 1.68 GB/s |
| Supported operating systems | Windows 2000/2003, Novell NetWare, Linux, IBM AIX, SUN Solaris, HP‑UX |
| Maximum number of drives | 224 drives (14 enclosures) |
| Dimensions (rack unit) | 4U, 174.5 mm H × 444.5 mm W × 609.6 mm D |
| Weight | 43.9 kg |
| Power input | 115 V‑230 V, 47‑63 Hz |
The system can store up to 168 TB of data.
It can support up to 224 drives by cascading up to 14 enclosures.
It supports RAID levels 0, 1, 3, 5, and 10.
The server works with Windows 2000/2003, Novell NetWare, Linux, IBM AIX, SUN Solaris, and HP‑UX.
