This manual introduces how to connect the TV, including antenna, cable box, VCR, DVD player and other devices.
This manual describes the front‑panel layout and all available input connections for the Philips 42PFL5422 TV, including HDMI, component, composite, S‑Video, PC (D‑SUB) and RF inputs. Detailed wiring diagrams and connector pin‑outs are provided for each source type.
Technical specifications such as dimensions, weight, power consumption and voltage requirements are listed, along with safety and environmental information. The guide also covers basic operation, menu navigation, and troubleshooting tips.
| Typical Power Consumption | 250 W |
|---|---|
| Input Voltage | 100‑240 V, 50‑60 Hz |
| Weight | 32 kg (70.7 lbs) |
| Dimensions (W×H×D) | 1181 x 803 x 362 mm |
The unit measures 1181 mm × 803 mm × 362 mm (width × height × depth).
The TV weighs approximately 32 kg (70.7 lbs).
