LM3S6100 Microcontroller Data Sheet is a data sheet about LM3S6100 microcontroller product of Luminary Micro company, introducing the features and characteristics of the product.
The LM3S6100 is a Stellaris‑class microcontroller based on an ARM Cortex‑M3 core. It integrates flash memory, SRAM, a range of timers, UART, SSI, Ethernet, analog comparator and other peripherals for embedded applications.
The document includes detailed block diagrams, pin‑out charts, electrical characteristics, register descriptions, programming commands, ordering part numbers and contact information for technical support. This manual is written in Chinese.
| Core | ARM Cortex‑M3 |
|---|---|
| Package | 100‑pin LQFP |
The LM3S6100 is ordered as part number LM3S6100‑IQC25.
The LM3S6100 is manufactured by Luminary Micro.
Technical support can be reached at [email protected] or +1‑512‑279‑8800.
