This is the user guide for HP mp3130 digital projector, introduces the features and characteristics of the product
This manual covers everything you need to set up and use the HP MP3130 digital projector. It includes a list of items shipped in the box, an overview of the projector’s buttons, indicators, rear panel connections, and remote control, as well as step‑by‑step installation guidance for tabletop, ceiling‑mount, and rear‑projection setups.
Later sections explain how to adjust focus, zoom, and image geometry, how to use the on‑screen menu for picture and audio settings, and how to perform routine maintenance such as cleaning the lens and replacing the lamp module. Technical specifications, safety and regulatory information, and a troubleshooting guide are also provided. This manual is written in Chinese.
| Brightness | 1800 ANSI lumens |
|---|---|
| Resolution | XGA (DLP) |
| Contrast ratio | 2000:1 |
| Video interface | M1-DA (digital and analog) |
| Super video input | Available |
| Composite video input | 1 RCA |
| Audio interface | Mini‑phone |
| Noise level | 37 dBA |
| Operating temperature | 10–35 °C |
| Storage temperature | -20–55 °C |
Rotate the Focus (聚焦) ring on the projector to focus the image within a range of 1.2 m to 12 m (4 ft to 40 ft).
The projector provides a brightness of 1800 ANSI lumens.
Use the M1‑to‑VGA/USB cable supplied in the box to connect the computer’s VGA or USB port to the projector.
