This manual describes the Philips HTS9800VY home‑theater speaker system, highlighting its Dolby EX and DTS audio processing, 1080i video up‑scaling, and wireless rear‑surround capability. It lists supported media formats such as DVD‑Video, SA‑CD, MP3, and various video codecs, and explains the system’s multi‑function remote control.
Technical details include dimensions (273 × 284 × 144 mm), total weight (47.5 kg), power consumption (165 W) and a universal 110‑240 V, 50/60 Hz power supply. The speaker array offers front, center, surround, and sub‑woofer outputs with up to 125 W per channel, HDMI, S‑Video, CVBS, and analog audio connections, as well as a range of equalizer presets. This manual is written in Chinese.
| Dimensions (W×H×D) | 273 x 284 x 144 mm |
|---|---|
| Weight (incl. packaging) | 47.5 kg |
| Power consumption | 165 W |
| Power supply voltage | 110-240V, 50/60 Hz |
| Front left/right output power | 125 W each |
| Supported audio formats | Dolby EX, DTS, Dolby |
| Supported video formats | MPEG‑1, MPEG‑2, DivX 3.11‑6.0 |
| HDMI output | Available |
| Subwoofer dimensions (W×H×D) | 300 x 399 x 300 mm |
| Subwoofer weight | 12 kg |
It supports Dolby EX, DTS and Dolby surround audio formats.
The video up‑scaling technology can increase resolution up to 1080i.
The system operates on a universal 110‑240 V, 50/60 Hz power supply.
