SCALANCE is a new type of active network component for building integrated networks. It includes SCALANCE X industrial Ethernet switches, SCALANCE W industrial wireless LAN, and SCALANCE S industrial security mechanisms. These products feature high performance, scalability, and security, making them suitable for harsh industrial environments.
This manual covers the Siemens SCALANCE X series of industrial Ethernet switches, including the X‑200, X‑300 and X‑400 variants. It provides detailed information on hardware features, supported protocols such as PROFINET, and compliance with IEEE 802.3 standards.
The document includes wiring diagrams, data‑rate options, part numbers, and contact information for technical support. It is intended for engineers and technicians who install, configure, and maintain these network devices in industrial environments.
| Maximum Data Rate | 1000 Mbit/s |
|---|---|
| Supported Ethernet Standard | IEEE 802.3 |
| Supported Protocol | PROFINET |
