MSP-320 is a tracker with safety warnings, product specifications, product introduction, product usage, tracker activation, and troubleshooting instructions. Users should use the product legally and protect the rights and privacy of others. The tracker uses GPS positioning and GSM communication module, with functions such as SOS emergency button and PARK button. Installation of SIM card and battery is required for use, and GPS data transmission interval can be freely set through the web platform.
The MSP-320 is a GPS/GSM tracking device that works on GSM 900/1800 MHz (or 850/1900 MHz) and supports GPRS Class 10. It includes a rechargeable 3.7 V battery, LED status indicators, an SOS button, and a Park mode for monitoring.
The manual covers safety precautions, SIM and battery installation, charging procedures, LED indicator meanings, how to activate SOS and Park functions, and a troubleshooting guide with common error symptoms and solutions. This manual is written in Japanese.
| GSM/GPRS Frequency | 900/1800 MHz |
|---|---|
| GPRS Class | Class 10 |
| GPS Antenna Sensitivity | 65 |
| Working Time per Fix (30 s) | ~9 hours |
| Working Time per Fix (1 min) | ~11 hours |
| Battery Capacity | 3.7 V 1050 mAh |
| Charger Input Voltage | 100‑240 V |
| Charger Output | 5 V 500 mA |
| Operating Temperature | -10 °C to +50 °C |
| Storage Temperature | -30 °C to +85 °C |
| GPS LED Color | Blue |
Insert the SIM card and battery in the correct direction as shown in the illustration on page 5.
Connect the charger to the charging port; the first charge takes about 4‑6 hours, subsequent charges take 2‑4 hours. The LED indicates charging status.
Press the SOS button for about 2 seconds to send an emergency SMS to the three pre‑registered contacts.
