PXI8996 synchronous acquisition card user manual, introduces the application, installation, component layout, signal connection, data format, AD function, application introduction and other contents
The PXI8996 is a PXI‑based synchronization acquisition card designed for test, measurement, and control applications such as manufacturing testing, industrial testing, and signal acquisition. It provides eight analog input channels, high‑resolution 24‑bit conversion, and flexible trigger options.
The manual includes a functional overview, hardware layout, installation checklist, software and hardware installation steps, signal connection methods, data format details, and application examples like automotive testing with LabVIEW integration. This manual is written in Chinese.
| Analog input range | +10 V |
|---|---|
| Conversion precision | 24 bits |
| Number of physical channels | 8 |
| On‑board clock frequency | 10 MHz |
The card provides eight analog input channels.
The default clock source is the on‑board 10 MHz oscillator.
Use the DIP switches (DID1) on the board to set the physical ID, with each switch representing a binary bit.
Insert the provided CD and run Setup.exe; the installer will guide you through the driver installation.
