This manual describes the basic operation, configuration menu usage, troubleshooting, and maintenance of the EPSON EB-1780W projector.
This manual provides safety instructions, a checklist of items included in the box, and detailed descriptions of the projector’s components and their functions. It guides users through installation, basic operation, image‑quality adjustments, and configuration menu usage.
The document also covers troubleshooting, maintenance procedures such as lamp and filter replacement, and lists all technical specifications and supported input ports. It is intended for end‑users of the Epson EH‑TW5500 projector sold in mainland China. This manual is written in Chinese.
| Model | EH‑TW5500 |
|---|---|
| Dimensions (W×H×D) | 450 mm × 136 mm × 360 mm |
| Resolution | 1920 × 1080 (2,073,600 pixels) |
| Panel size | 0.74 inch (wide) |
| Lamp | UHE lamp, 200 W, model ELPLP49 |
| Power supply | 100‑240 V AC ±10% 50/60 Hz |
| Power consumption (100‑120 V) | 97 W (operating), 0.2 W (standby) |
| Weight | ≈7.5 kg |
