This document introduces the features and characteristics of the ZTE-T M501 60PIN B2B module, including hardware features, reliability, logic level characteristics, antenna performance technical requirements, structural dimensions, size matching precautions, hardware system architecture, software system architecture, business and applications, interfaces, etc.
The ZTE‑T M501 is an industrial‑grade embedded communication module that supports multiple mobile network standards such as TD‑SCDMA, HSDPA, HSUPA, GSM, GPRS and EDGE. It can be used in laptops, MID devices, e‑readers, wireless radios, access boxes, remote monitoring, vehicle terminals and other M2M applications.
The manual covers the module’s external appearance, main features, technical specifications, hardware and software system architectures, and a range of interfaces including UART, USB, SIM/USIM, audio and antenna connectors. It also details reliability limits, power interfaces, debugging environments, and pin‑level signal definitions for developers and integrators. This manual is written in Chinese.
| Connector type | 60‑pin B2B |
|---|---|
| Supported network standards | TD‑SCDMA, HSDPA, HSUPA, GSM, GPRS, EDGE |
| USB power input | 5 V USB |
It supports TD‑SCDMA, HSDPA, HSUPA, GSM, GPRS and EDGE mobile network standards.
The module uses a 60‑pin B2B connector for its primary input/output signals.
