This document is the user manual for ZXR10 5009 (V1.0) Gigabit Access Switch released by ZTE Corporation. The manual provides information on the safety instructions, system overview, structure and principles, installation and debugging, and usage and operation of the product.
This manual covers all aspects of the ZXR10 5009 gigabit access switch, including safety guidelines, system overview, hardware structure, installation steps, configuration methods, system management, service and network configuration, routine maintenance, and a full command reference.
The document is organized into ten chapters plus an appendix of acronyms, offering detailed procedures for console, Telnet, SNMP, and web configuration, as well as guidance on firmware upgrades, backup, and troubleshooting. This manual is written in Chinese.
| Connector model | E5088-001023 |
|---|---|
| Rated current | 1.5A |
| Rated voltage | 125V |
The manual uses the symbols 注意, 小心, 警告, and 危险 to highlight important safety information.
The command reference is provided in Chapter 10 of the manual.
The switch uses an 8P8C straight‑type RJ45 crimp connector, model E5088-001023, rated at 1.5 A and 125 V.
