The SRP-X500P is a multi-purpose digital powered mixer that integrates an audio mixer, RGB/video signal converter, processor and power amplifier in a 3U rack. The product has preset AV system type settings, projector control, built-in digital mixer, multiple audio input/output interfaces, compatible with composite/RGB/component signals, etc.
This manual covers safety precautions, installation steps, and detailed operation of the Sony SRP‑X500P digital powered mixer. It describes the front and rear panel functions, control interfaces, and how to configure audio inputs, speaker outputs, and projector control.
The document also includes specifications, indicator light meanings, and troubleshooting guidance, along with software requirements for using the included CD‑ROM manager program on a PC. This manual is written in Japanese.
| Power Amplifier Output | 90W+90W+30W+50W (8Ω or 4Ω) |
|---|---|
| High‑Impedance Speaker Support | 60 W, 70 V LINE, 8 Ω |
| Operating Temperature Range | 0 °C to 40 °C |
| Video Input Support | 480p, 1080i, SXGA (1280 × 1024) RGB/component |
It can operate in ambient temperatures from 0 °C to 40 °C.
The unit provides four speaker outputs (CH‑1 to CH‑4).
It includes 90 W + 90 W + 30 W + 50 W power amplifiers, selectable for 8 Ω or 4 Ω loads.
Projector control can be performed via RS‑232C or CONTROL S IN/OUT interfaces.
