The SINAMICS G130 and G150 are high‑performance frequency converters designed for single‑machine transmission applications such as pumps, fans, conveyors, and extruders. They offer a wide power and voltage range, modular design, and advanced pulse‑edge modulation for 100% motor voltage without harmonic penalties.
This manual covers product overview, technical features, component options, quick selection tables, installation and commissioning procedures (including AOP30 and BOP20 panels and STARTER software), and service/maintenance guidelines. It also provides detailed specifications and contact information for Siemens support. This manual is written in Chinese.
| Power range | 0.12 kW ~ 120 MW |
|---|---|
| Voltage range | 220 V ~ 10 kV |
| Typical noise level | < 69 dB(A) |
| Power rating (380‑480 V) | 110 ~ 560 kW |
| Power rating (500‑600 V) | 110 ~ 1 000 kW |
| Power rating (660‑690 V) | 75 ~ 1 500 kW |
It supports a wide voltage range from 220 V up to 10 kV.
The typical noise level is less than 69 dB(A).
