This is a user manual for a video recorder produced by Sony Corporation
This manual begins with safety precautions, including warnings about dangerous voltage, proper grounding, and environmental conditions to protect the recorder and users. It then guides you through the quick set‑up process, connecting the unit to a TV via RF, SCART, or S‑Video cables, and configuring the auto‑set‑up function for tuner channels, clock, and video channel.
Subsequent sections cover basic and advanced operations such as playback, recording modes, timer programming, picture adjustment, and remote‑control functions. The document also includes system‑connection details, subsidiary settings, a troubleshooting Q&A, and a full specifications table for power, dimensions, tuner ranges, and audio/video performance.
| Weight | 4.8 kg |
|---|---|
| Tuner frequency range | VHF 44.5‑143 MHz, UHF 143‑470 MHz |
| Adjustable UHF range | 470‑862 MHz |
| Audio frequency response | 70 Hz‑10 kHz (normal), 20 Hz‑20 kHz (Hi‑Fi) |
| Memory backup time | Approx. 10 min |
