The NET2860 DAQ card is a data‑acquisition device that can be connected to an IBM‑PC/AT or compatible computer for signal collection, waveform analysis and control applications. It supports multiple input ranges, high‑speed sampling and provides status LEDs for power, data collection and error conditions.
The manual includes a functional overview, detailed component layout, signal I/O descriptions, data format, installation procedures, safety notes, calibration steps and warranty information, helping users set up and operate the card correctly. This manual is written in Chinese.
| Input voltage range | ±5 V, ±10 V, 0‑10 V, 0‑5 V |
|---|---|
| Resolution | 16 bit |
| Number of input channels | 8 or 16 single‑ended, 8 differential |
| Operating temperature range | -40 °C to +85 °C |
| Storage temperature range | -40 °C to +120 °C |
The card supports ±5 V, ±10 V, 0‑10 V and 0‑5 V input ranges.
It provides 8 or 16 single‑ended channels and 8 differential channels.
