Yokogawa GA10/GA10CL/GA10UP Error Codes

73 codes from pages 152–155 of the manual

This is the list of error codes the Yokogawa manual gives for the GA10/GA10CL/GA10UP Yokogawa GA10/GA10CL/GA10UP. Find your code below and open it for what the manual says about its causes and what to do.

Error codes from p. 153

CodeWhat it meansPage
E3001 Unable to connect to the specified server. p. 153
E3002 Login failed. Please confirm the user name or the password. p. 153
E3003 Connected clients has reached maximum, you can not log in. p. 153
E3004 Unable to connect to the server. p. 153
E3005 The user name already exists, the user can not be registered. p. 153
E3006 The password is incorrect. p. 153
E3007 Please enter at least four characters for the password. p. 153
E3008 The new password and the confirmed password does not match. p. 153
E3009 You can not delete the logged user. p. 153
E3010 Users to change is logged into the server. The basic information can not be changed. p. 153
E3011 User to be initialized is logged in to the server, user can not be initialized. p. 153
E3012 The maximum number of logins has been reached, the user can not log in. p. 153
E3013 Since the Project name you entered already exists, the project can not be created. p. 153
E3014 Since the Project name you entered already exists, you can not change it. p. 153
E3015 The Project which is opening, can not be deleted. p. 153
E3016 The Project which is running, can not be deleted. p. 153
E3017 The maximum number of registered devices has been reached, the device cannot be registered. p. 153
E3018 The equipment in use can not to be removed. p. 153
E3019 Original owner is opening projects, you cannot change the owner. p. 153
E3020 Server can not receive device information. p. 153
E3021 Fail to create record folder. p. 153
E3022 Failed to start Universal Viewer. p. 153
E3023 An error occurred while reading the file. p. 153
E3024 An error occurred while writing the file. p. 153
E3025 User manual does not excist in the specified location. p. 153
E3026 Failed to start Adobe Reader. p. 153
E3027 Simultaneous running projects has reached the maximum number, failed to start monitoring. p. 153
E3028 Because the maximum concurrent number of connected devices is reached, collecting cannot start. p. 153
E3029 Because the maximum device number that can be registered is reached, the Project can not be created. p. 153
E3030 Because the maximum number of open projects is reached, the project cannot be opened. p. 153
E3031 Failed to delete data file. p. 153
E3032 Failed to open data files. p. 154
E3033 Fail to launch web browser. p. 154
E3034 Operation failed because there is no right to access Project. p. 154
E3035 Operation failed because the target user does not exist. p. 154
E3036 Fail to import project because registered devices reach the maximum number. p. 154
E3037 Project is closed, because Project lock status is released forcibly. p. 154
E3038 Operation failed because the project is locked by another user. p. 154
E3039 Specified new owner does not exist, you can not change the owner. p. 154
E3040 Operation failed because Project is deleted. p. 154
E3041 Serial no is invalid. Activation failed. p. 154
E3042 Server has not been activated. Adding option to software failed. p. 154
E3043 Tag upgrade option's serial no is invalid. Fail to add option's serial no. p. 154
E3044 Part of the data files can not be deleted. p. 154
E3045 Part of the data files can not be opened. p. 154
E3046 Failed in registration. The administrator authority is required. Please restart as an administrator or run as administrator and restart. p. 154
E3047 Insufficient memory available to the OS. Operation failed. p. 154
E3048 Since the number of tags in the imported project configuration information exceeded the number of tags supported by the current server failed to import. p. 154
E3049 Failed to operate some projects or all project at once. p. 154
E3050 Insufficient memory available to the OS. Project will close. p. 154
E3051 Fail to start monitoring because the necessary setting is not correct. p. 154
E3052 Operation failed because device has been deleted. p. 154
E3053 Searching is not allowed because auto-search in progress. p. 154
E3054 Failed to update the information of some specified tags or all tags. p. 154
E3055 Cannot write to specified recording folder. p. 155
E3056 Connecting this version's server is not available. p. 155
E3057 Failed to install the certificate. p. 155
E3058 The license is already in use. p. 155
E3059 Failed to register the template file. p. 155
E3060 Failed to download the template file. p. 155
E3061 Failed to delete the template file. p. 155
E3062 Failed to delete the schedule. p. 155
E3063 Excel is not installed. p. 155
E3064 Can not open the report file. p. 155
E3065 Failed to generate a report file. p. 155
E3066 Failed to print. p. 155
E3067 Failed to issue a certificate signing request. p. 155
E3068 The option is already enabled. p. 155
E3069 Failed to start the OPC-UA server. The port number is already in use. p. 155
E3070 The server certificate is invalid. p. 155
E3071 Can not import the project. It contains unavailable function. p. 155
E3072 Failed to generate a self-signed certificate. p. 155
E3073 Failed to paste project. p. 155
