Red Manuals

Key facts

Manuals

31

Models

2

Languages

ZH · EN

Last added

2012-08-08

Red models by category

Featured Red manuals

Red Flag Server 4.1 Advanced Management Manual

User Manual 114 pages · 2.3 MB · ZH

The Advanced Management Manual for Red Flag Server 4.1 is intended for system administrators and advanced users who already know the basic operation of the OS. It explains the background and operation of high‑level features such as advanced file systems, software RAID, logical volume management, kernel upgrade tools, and asynchronous I/O.

The manual includes command syntax examples, configuration file samples, and step‑by‑step procedures for creating and managing LVM volumes, snapshots, and RAID devices. Appendices provide a glossary, common questions, and reference information on Unix concepts such as shadow passwords and shells. This manual is written in Chinese.

Covers: Advanced Feature Overview · Advanced File System Guide · Software RAID Device Creation · LVM (Logical Volume Management) Manual · Kernel Upgrade Tool · Asynchronous I/O Guide

Latest Red manuals

• Red Hawk RTF - HCAA1960 manual

  This is an airplane model produced by Hobbico, and the instruction manual introduces the assembly and flight characteristics.

• Red One Operation Manual

  This document describes the features and characteristics of the camera product produced by Red.com, Inc.

• Red Hat x86 Itanium AMD64 Intel Extended Memory 64 Technology Installation Guide

  This document is an installation guide for Red Hat Enterprise Linux 4, covering x86, Itanium™, AMD64, and Intel® Extended Memory 64 Technology (Intel® EM64T) platforms. It provides instructions and considerations for the installation process.

• RED LION CONTROLS Industrie - Temperaturanzeige PAX T

  This document describes an industrial temperature display called PAX T. The display features a 5-digit, 14mm high LED screen that is readable in sunlight. It supports 20 measurements per second and can be used with thermocouples, Pt100, and ohm options. It has 2 or 4 plug-in limit values and analog outputs of 0-10V and 0/4-20mA. The display has a high protection rating of IP65 and dimensions of 48 x 96 x 104mm. It also supports various serial communication interfaces such as PROFIBUS-DP, RS232, and RS485. The display has a user-friendly interface and can be programmed via PC or directly on the device.

• RED LION CONTROLS MODEL PAXLRT - PAX LITE RTD METER

  The Pax Lite RTD Meter accepts standard RTD inputs and precisely linearizes them into temperature readings. It features a selectable Fahrenheit or Celsius display with 0.1 or 1 degree resolution. The meter utilizes state-of-the-art digital electronics for greater accuracy and reliability. It also offers programmable temperature offset, digital filtering, peak/valley memory, and a sealed front bezel.

• RED LION CUB5P DATA SHEET

  The CUB5 Series provides the user the ultimate in flexibility, from its complete user programming to the optional setpoint control and communication capability. The CUB5 accepts a DC voltage or current input signal and provides a display in the desired unit of measure. The meter also features minimum and maximum display capture, display offset, units indicator, and programmable user input. The display can be toggled either manually or automatically between the selected displays. The CUB5 display has 0.48" (12.2 mm) high digits. The LCD is available in two versions, reflective or red/green backlight. The backlight version is user selectable for the desired color and also has variable display intensity. The capability of the CUB5 can be easily expanded with the addition of option modules. The setpoint output cards are field installable with programmable setpoints. Serial communications capability for RS232 or RS485 can be added with a serial option module.

• red lion T16 P16 - TEMPERATURE/PROCESS CONTROLLERS

  The Model T16 Controller accepts signals from a variety of temperature sensors (thermocouple or RTD), while the Model P16 Controller accepts either a 0 to 10 VDC or 0/4 to 20 mA DC input signal. Both controllers can provide an accurate output control signal (time proportional or DC Analog Output) to maintain a process at a setpoint value. Dual 4-digit displays allow viewing of the process/temperature and setpoint simultaneously. Front panel indicators inform the operator of the controller and output status. The comprehensive programming allows these controllers to meet a wide variety of application requirements.

• RED LION CUB5 Manual

  The CUB5 is a modular counter with optional relay output modules and serial communication modules. The counter has an 8-digit LCD display that can display values and units, and it is available in a reflective or backlight version with variable display intensity. The counter can be programmed as a single counter or dual counter, and it has a rate indication function. The counter can be programmed for 8 different counting modes, including bidirectional and quadrature counting modes. When programmed as a dual counter, each counter has a separate scale factor and decimal point. In the counter/rate indicator mode, each counter has its own scale factor and decimal point readings in different engineering units. The counter has two independent inputs, and the function of the counter depends on the polarity and frequency of the input signal.

• RED LION MODEL PAX - 1/8 DIN DIGITAL INPUT PANEL METERS Manual

  The PAX Digital Input Panel Meters offer many features and performance capabilities to suit a wide range of industrial applications. It has counting, rate, and alarm functions, and can be connected to various communication and bus interfaces.

• RED LION DITAK 8 - ADJUSTABLE TIMEBASE 5-DIGIT RATE INDICATOR

  This is a self-powered rate indicator with adjustable timebase and yellow/green or red backlighting. It features a 5-digit LCD display with 0.6 inch high digits, available in positive image reflective (black digits, reflective background) or negative image transmissive (illuminated digits, dark background) with red or yellow/green backlighting. The unit is constructed of a lightweight, high impact plastic case with a clear viewing window. The sealed front panel meets NEMA 4X/IP65 specifications for wash-down and/or dusty environments, when properly installed.

• RED LION CONTROLS MODEL CUB5RT - MINIATURE ELECTRONIC 5-DIGIT RTD METER

  The CUB5 is a highly flexible electronic 5-digit RTD meter, offering complete user programming and optional setpoint control and communication capabilities. It accepts RTD input and provides temperature display in Celsius or Fahrenheit, with features including minimum and maximum display capture, display offset, °F or °C indicator, and programmable user input.

• RED LION CONTROLS MODEL CUB70 CUB7W - MINIATURE ELECTRONIC 8 DIGIT COUNTER Manual

• RED LION CONTROLS CUB5I - MINIATURE ELECTRONIC 5-DIGIT DC CURRENT METER Manual

  The CUB5I is a miniature electronic 5-digit DC current meter with four selectable DC current ranges and minimum and maximum display capture. It features an LCD display with reflective or red/green LED backlighting. Optional setpoint output modules and serial communications modules are available. It operates from a 9 to 28 VDC power source and can be programmed using the front panel or Crimson software.

• RED LION CONTROLS - 1 AVAILABLE IN 6 OR 8-DIGIT VERSIONS 6-DIGIT 0.56\" (14.2 mm) 8-DIGIT 0.4\" (10.1 mm) HIGH LED

  The PAX Lite Counter is a versatile totalizing counter that can be adapted to a wide variety of counting, measuring, and positioning readout applications. It features a programmable scale factor, front panel and remote reset, store, inhibit, and a count rate of 25 KHz, while offering an economical solution to any totalizing need. The PAXLC accepts digital inputs from a variety of sources including switch contacts, NPN-OC and TTL outputs, as well as most standard Red Lion sensors. The input can be scaled to display any desired unit of measure by simply using the programmable scale factor. The meter can accept bi-directional and uni- directional signals. The meter is programmed through the front panel buttons and the use of DIP switches. The Down Arrow Key will also function as a front panel display reset. Once the front panel programming is complete, the buttons can be disabled by a DIP switch setting. The meter has been specifically designed for harsh industrial environments. With a NEMA 4X/IP65 sealed bezel and extensive testing to meet CE requirements, the meter provides a tough yet reliable application solution.

• RED LION MODEL CUB7T1 PROGRAMMABLE GENERAL PURPOSE ELECTRONIC TIMER

  CUB7T1 is a 8-bit miniature programmable timer produced by DELIXI Electrical. It has a large 0.35 inch (8.90 mm) high digit, with positive image reflective (CUB7T100), negative image transmissive with yellow/green backlighting (CUB7T110) or red backlighting (CUB7T120) display options. The backlit versions require an external 9 to 28 VDC power supply. When an overflow occurs, the display will wrap around from a full display of “99999999” to “00000000”. An annunciator, located in the upper left hand corner of the display, blinks at 2 Hz when the signal input is activated. The voltage versions (CUB7T1xxx) operate from a signal voltage of 10 to 300 V (AC 50/60 Hz or DC). The CUB7T timers use a CMOS LSI chip, mounted on a gold-plated substrate, that is electrically connected by ultrasonic wire-bonding. Proven micro-electronic assembly and manufacturing techniques provide these units with the reliability and dependability required for industrial service. The CUB7T series is housed in a lightweight, high impact plastic case with a clear viewing window.

Which document do I need?

Questions answered in Red manuals
