Key facts
- Brand
- ZLG
- Model
- P9103
- Documents
- 2
- Languages
- ZH
- Last added
- 2011-09-21
Start here
ZLG P89LPC9102/9103/9107 Microcontroller User Manual
User Manual 76 pages · 677 KB · ZH
This manual introduces the P89LPC9102, P89LPC9103, and P89LPC9107 microcontrollers, highlighting their high‑integration, low‑cost design and the range of built‑in functions such as timers, UART, ADC, DAC, and flash memory.
It details pin symbols, package options, clock configuration, interrupt handling, and programming instructions, giving developers the information needed to integrate the devices into their circuits. This manual is written in Chinese.
ZLG P9103 specifications
| Flash memory | 1 kB |
|---|---|
| RAM | 128 bytes |
| Timers | Two 16‑bit timers |
| ADC channels | 4‑channel 8‑bit ADC |
| I/O voltage range | Vpp 2.4‑3.6 V, pins up to 5.5 V |
All ZLG P9103 documents by type
User Manual 2
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Product Leaflet 1
Questions answered in these manuals
What is the flash memory size of the P89LPC9102/9103/9107?
Each device provides 1 kB of byte‑addressable flash memory that can be erased per byte.
How many ADC channels are available?
The microcontroller includes a four‑channel 8‑bit ADC.
