TAKSTAR DA-237 User Manual(1)
The VI RAM Ripple Attenuator Module is designed to lower output ripple on VI‑200/VI‑J00 based power supplies to less than 3 mV peak‑to‑peak. It works with a wide input range of 5 V to 50 V DC and can deliver up to 20 A of continuous current without requiring any user adjustments.
Key specifications include input and output voltage ranges of 5‑50 VDC, ripple performance of 3 mV pk‑pk (VI‑2) and 10 mV pk‑pk (VI‑J), efficiency between 93 % and 99 %, and a compact PCB mounting size of 58 × 61 × 13 mm. The module meets multiple temperature grades and standard approvals for reliable operation.
Takstar DA-237 specifications
| Input voltage range | 5–50 VDC |
|---|---|
| Output voltage range | 5–50 VDC |
| Maximum output current | 20 A |
| Ripple (VI‑2) | 3 mV pk‑pk |
| Efficiency | 93 %–99 % |
| Operating temperature (E‑Grade) | -10 °C to +100 °C |
| PCB mounting package | 58 × 61 × 13 mm |
