softing CAN-PRO2-PCIE Manual
The CAN-AC2-PCI is a PCI card that provides two independent CAN bus channels with galvanic isolation, designed for vehicle electronics engineering, test, and manufacturing environments. It supports high‑speed CAN by default and can be equipped with optional low‑speed transceivers via piggyback modules.
The manual includes technical data such as power supply, memory, and temperature ranges, as well as delivery scope, system requirements, and optional accessories. It also describes the CAN‑API software and D‑PDU API for multi‑channel communication and diagnostic applications.
Softing CAN-AC2-PCI specifications
| Power supply | 5V (via PC) |
|---|---|
| Current consumption | Typ. 410 mA |
| Microcontroller | Infineon C165 |
| Program/data memory | 256 kB RAM (via download) |
| PCI interface | PCI V2.1, 4 kB DPRAM (16‑bit) |
| CAN controller | SJA1000 |
| Operating temperature range | 0 °C … +55 °C (operation), -20 °C … +70 °C (storage) |
| CAN channels | 2 independent channels, ISO 11898, CAN 2.0B, 11/29‑bit identifiers |
| Connectors | 2 × D‑Sub 9‑pin, galvanically isolated |
Source: softing CAN-PRO2-PCIE Manual
All Softing CAN-AC2-PCI documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What power supply does the CAN-AC2-PCI require?
It operates from a 5 V supply provided by the PC.
How many CAN channels are supported?
The card provides two independent CAN bus channels.
