Key facts
- Brand
- Sakura
- Model
- SR-2886
- Category
- Air Cleaners Purifiers
- Documents
- 2
- Languages
- EN · ZH
- Last added
- 2012-04-09
Start here
Sakura SR-2886 Range Hood User Manual
User Manual 12 pages · 2.3 MB · EN
This manual covers all steps needed to install the Sakura SR-2886 range hood, including wiring, mounting height, and securing the exhaust duct. It also explains how to operate the motor speed, lighting, and oil‑tray functions.
Safety guidelines, daily cleaning procedures, and detailed technical specifications are provided to ensure reliable performance and long service life. Contact information for service and spare parts is included at the end of the document.
Sakura SR-2886 specifications
| Dimensions (W×D×H) | 710 mm × 565 mm × 160 mm |
|---|---|
| Voltage | 220 V 50 Hz |
| Motor type | Internal rotor twin motors |
| Exhaust hole diameter | 152 mm |
| Lamp | 40 W white bulb |
| Motor speed | Low 1500 RPM / High 1600 RPM |
| Air exhaust volume | 900 m³/h (high) / 760 m³/h (low) |
| Power consumption | 165 W |
All Sakura SR-2886 documents by type
User Manual 2
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
How many motor speed settings does the range hood have?
It has two speed settings: low at 1500 RPM and high at 1600 RPM.
What installation height is required for the range hood?
The bottom of the hood must be at least 65 cm above the cooking surface.
What voltage should be used to power the hood?
Connect the hood to a 220 V, 50 Hz power supply.
