Novus N321/N322/N323 Temperature Controllers User Guide
This document is the user guide for the Novus N321, N322, and N323 temperature controllers, which are designed for heating and cooling applications. The models are distinguished by the number of output channels available (one for N321, two for N322, and three for N323) and the type of temperature sensor supported (NTC, Pt100, or J/K/T thermocouples).
Read onlineNovus N323 specifications
| Input Sensor Options | NTC Thermistor, Pt100, Pt1000, J/K/T thermocouple |
|---|---|
| Warm-up Time | 15 minutes |
| Power Supply (Mains) | 100-240 Vac or 24 Vdc/ac |
| Dimensions | 74 x 32 x 75 mm |
| Communication Interface | RS-485 digital communication; RTU MODBUS protocol (optional) |
All Novus N323 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
How many outputs does the N323 have?
The device features three independent outputs that can be used as control or alarm functions.
How do I access the configuration parameters?
Press and hold the UP key for 2 seconds until the 'int' message appears to enter Level 2.
What are the differences between the N321, N322, and N323 models?
The models are distinguished by the number of outputs available: N321 has 1 output channel, N322 has 2, and N323 has 3.
From: Novus N321/N322/N323 Temperature Controllers User Guide
What types of temperature sensors are supported?
The controllers support NTC, Pt100, and J/K/T thermocouple sensors, depending on the specific model purchased.
From: Novus N321/N322/N323 Temperature Controllers User Guide
