Myir MYC-Y6ULX Manuals

ManualLib has 3 documents for the Myir MYC-Y6ULX (Other): 2 datasheets, 1 user manual. Every file can be read online or downloaded as a PDF for free.

Datasheet 2User Manual 1

Key facts

Brand
MYiR
Model
MYC-Y6ULX
Category
Other
Industry
Computers
Documents
3
Languages
ZH · EN
Last added
2026-10-04

Start here

MYIR MYC-Y6ULX Product Manual

MYIR MYC-Y6ULX Product Manual

User Manual 32 pages · 1.4 MB · EN

The MYC-Y6ULX is a high-performance, low-cost CPU module by MYIR based on NXP's i.MX6UL/6ULL processor family. It supports various memory interfaces and peripherals for embedded development. The manual details hardware characteristics, pin assignments, schematics, and development tools. It also includes maintenance guidelines, warranty terms, and support services for users.

The module comes in different configurations with varying memory and performance specs, including options for DDR3L, NAND Flash, eMMC, and Ethernet. MYIR provides software resources, BSP packages, and driver support. Maintenance and warranty policies are outlined, including shipping costs and RMA procedures for repairs.

Read online

Myir MYC-Y6ULX specifications

CPU coreARM Cortex‑A7
Maximum CPU frequency900 MHz
Memory (DDR)256 MB DDR
Board dimensions37 mm × 39 mm × 3 mm
GPIO high‑level input voltage (VIH)2.3 V – 3.3 V

Source: Myir MYC-Y6ULX Embedded Board Datasheet

All Myir MYC-Y6ULX documents by type

Datasheet 2

Ratings, dimensions and ordering codes, for selection and design work.

User Manual 1

Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.

Questions answered in these manuals

What are the physical dimensions of the MYC‑Y6ULX board?

The board measures 37 mm by 39 mm with a thickness of 3 mm.

From: Myir MYC-Y6ULX Embedded Board Datasheet

Which processor core does the MYC‑Y6ULX use?

It uses an NXP i.MX6UL/6ULL processor based on an ARM Cortex‑A7 core.

From: Myir MYC-Y6ULX Embedded Board Datasheet

What is the commercial operating temperature range?

The commercial version operates from 0 °C up to +70 °C.

From: Myir MYC-Y6ULX Datasheet

What is the recommended power‑up sequence for the board?

The CPU main power must be applied before any peripheral power to avoid startup issues.

From: Myir MYC-Y6ULX Datasheet

What kind of memory options are available?

The module supports DDR3L, NAND Flash, eMMC, and Quad SPI memory interfaces.

From: MYIR MYC-Y6ULX Product Manual

What is the warranty and maintenance policy?

MYIR offers free maintenance for quality issues within warranty, charges material costs for out-of-warranty repairs, and covers return shipping for warranty repairs.

From: MYIR MYC-Y6ULX Product Manual
