Ascend AD404M42V 4Mx4 EDO Data Sheet
The Ascend AD404M42V is a 4 Mx 4 EDO dynamic RAM organized as 4,194,304 words × 4 bits. It operates from a single 3.3 V supply and is offered in standard JEDEC‑compliant 26/24‑pin plastic SOJ or TSOP II packages. The device features high‑speed access times (5 ns, 200 MHz) and low power dissipation, making it suitable for battery‑backed portable electronics.
Key specifications include a supply voltage range of –0.5 V to +4.6 V, operating temperature from 0 °C to +70 °C, and various density options (1 M‑bit to 16 M‑bit). Detailed pin configurations, block diagrams, and timing tables are provided for design integration.
Ascend 4MX4 specifications
| Density options | 1 M‑bit to 16 M‑bit |
|---|---|
| Minimum cycle time | 5 ns (200 MHz) |
| Package types | 26/24‑pin plastic SOJ, TSOP II |
| Supply voltage range | -0.5 V to +4.6 V |
| Operating temperature | 0 °C to +70 °C |
| Power dissipation | 1.0 W |
| Input capacitance (Address) | 5 pF |
