Key facts
- Brand
- Advantech
- Model
- ADAM-5000/TCP
- Industry
- Industrial
- Documents
- 2
- Languages
- EN
- Last added
- 2026-10-14
Start here
Advantech ADAM-5000/TCP System User Manual
The document serves as a comprehensive guide for the Advantech ADAM-5000/TCP system, detailing its features, specifications, and integration into SCADA environments. It explains how to select appropriate hardware components, including various isolated and non-isolated I/O modules for analog, digital, relay, and serial communication tasks.
The manual provides step-by-step instructions for physical installation, such as panel mounting and DIN rail mounting, along with detailed wiring diagrams for power supply and network connections. It also covers system configuration using Windows Utility software, security settings, calibration procedures, and firmware updates.
Advantech ADAM-5000/TCP specifications
| Response time | < 5 ms |
|---|---|
| Main unit slots | 8‑slot (ADAM-5000/TCP) / 4‑slot (ADAM-5000L/TCP) |
| Maximum I/O points | 128 |
| Ethernet speed | 10 Mbps – 100 Mbps (auto‑switching) |
Source: Advantech ADAM-5000/TCP Series Distributed DA&C System User Manual
All Advantech ADAM-5000/TCP documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What is the warranty period for Advantech products?
Advantech warrants that each product will be free from defects in materials and workmanship for two years from the date of purchase.
How do I request a Return Material Authorization (RMA) number?
You must access Advantech's RMA website to request an RMA number if your product is diagnosed as defective.
How do I assign addresses to I/O modules?
Address assignment is described in section 3.5 "Assigning address for I/O Modules" of the manual.
From: Advantech ADAM-5000/TCP Series Distributed DA&C System User Manual
How can I update the firmware of the system?
Firmware updates are performed via the "5.3.5 Firmware Update" procedure shown in the manual.
From: Advantech ADAM-5000/TCP Series Distributed DA&C System User Manual
