Key facts
- Brand
- 帅康集团
- Model
- CXW-200
- Category
- Air Cleaners Purifiers
- Industry
- Appliances
- Documents
- 6
- Languages
- ZH
- Last added
- 2000-01-01
Start here
Shuai Kang CXW-200-T799 Range Hood Installation Manual
This manual provides step‑by‑step instructions for installing the Shuai Kang CXW‑200‑T799 range hood, including wiring diagrams, clearance requirements, and connection to compatible stove models. It also describes the control panel functions such as fan speed, lighting, and stove‑hood linkage.
Additional sections cover daily maintenance, safety precautions, warranty terms, and service contact information. Technical data such as motor power, noise level, and LED lighting are listed for reference. This manual is written in Chinese.
帅康集团 CXW-200 specifications
| Air flow | 15 m³/min |
|---|---|
| Noise level | 54 dB |
| Static pressure | >300 Pa |
| Net weight | 22 kg |
Source: Sacon CXW-200-TF05/CXW-200-TF03/CXW-200-TF06/CXW-200-TF16 range hood makeuse installation Manual
All 帅康集团 CXW-200 documents by type
Mounting, wiring and first power-up. Read it before the hardware goes in.
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
How do I install the range hood on the wall?
Drill a 185 mm wall opening, insert the expansion tube, and secure the mounting bracket and foot with wood screws as shown in the diagram.
From: Sacon CXW-200-TF05/CXW-200-TF03/CXW-200-TF06/CXW-200-TF16 range hood makeuse installation Manual
How can I set the delayed shut‑off timer?
Press the “Delay” key, then use the “+” or “–” keys to set a time between 1 and 15 minutes; the timer starts automatically after three seconds of inactivity.
From: Sacon CXW-200-TF05/CXW-200-TF03/CXW-200-TF06/CXW-200-TF16 range hood makeuse installation Manual
How do I set the delayed shutdown time?
Press the "设置" (Set) key, then hold the "延时" (Delay) key; the time will increase from 01 to 99 minutes in one‑minute steps.
From: Shuai Kang CXW-200-T799 Range Hood Installation Manual
How can I change the fan speed?
Press the "风量" (Fan Speed) key repeatedly to cycle through high, medium, low, and off positions, with the corresponding symbol shown on the display.
From: Shuai Kang CXW-200-T799 Range Hood Installation Manual
How should the range hood be installed in the wall?
A wall opening of 185 mm diameter should be cut, and the exhaust pipe is extended about 30 mm outside the wall before being secured with the supplied brackets and screws.
How often should the filter be cleaned?
It is recommended to clean the filter with a soft cloth and detergent about every two weeks.
