Technical specifications for the Yokogawa 01E30A01-01C-C level transmitter, covering measurement range, power supply, materials and accuracy.
The Yokogawa 01E30A01-01C-C is a level transmitter designed for reliable measurement in challenging fluid conditions. It features dual‑magnetic excitation, LCD display, and optional digital output for integration with DCS systems.
The datasheet provides detailed technical data such as nominal pipe diameter, power supply voltage, construction materials, operating temperature range, and measurement accuracy. Installation notes and safety warnings are also included to ensure proper use.
| Nominal Diameter | 25 – 100 mm |
|---|---|
| Power Supply | 14.7 – 35 V DC |
| Output | Digital output (optional analog/alarm) |
| Body Material | JIS SUS316L (AISI 316L) |
| Wetted Parts Material | C276 alloy |
| Measurement Accuracy | ±0.5 % of flow rate |
| Excitation Method | Dual magnetic |
The transmitter operates from 14.7 to 35 V DC.
It provides an accuracy of ±0.5 % of the flow rate.
The wetted parts are made of C276 alloy, and the body uses SUS316L stainless steel.
