The XYK-100 projector controller manual explains installation, RS232 code programming, wiring, and operation of the controller.
This manual describes the XYK-100 projector controller, a device that manages power‑on, power‑off and signal source selection for projectors. It details safety considerations, the controller’s automatic cooling delay, and how the controller communicates with the projector via RS232.
Installation steps cover connecting the controller to power and the projector, creating the RS232 control cable, and using the provided software to write and verify control codes. Operational instructions explain turning the projector on and off, selecting VGA/VIDEO input, and troubleshooting code mismatches. This manual is written in Chinese.
| Input Voltage | ≤~220V/5 A |
|---|---|
| RS232 Connector (standard) | 9‑pin rectangular socket |
| RS232 Connector (alternative) | 8‑pin circular socket (optional) |
Turn on the controller’s power switch; the controller supplies power to the projector and automatically sends the power‑on RS232 code.
For the standard 9‑pin connector, pin 5 is ground and pin 2 is data receive; some projectors use pin 3 for data receive.
