Technical overview, specifications and ordering information for the VERO + Danica VP80‑4 open‑frame AC‑DC power supply.
The VERO + Danica VP80‑4 is an open‑frame, 19‑inch rack‑mountable power supply designed for telecom and industrial applications. It features active power factor correction, a wide input voltage range and multiple output options, all housed in a compact steel‑and‑aluminium cassette.
EA‑Elektro‑Automatik, the original equipment manufacturer, provides both standard and custom solutions, with compliance to EN‑60950, UL‑1950 and EMC directives. The catalogue also lists related VP, PK, EC and TPS series, as well as ordering codes and connector options.
| Input voltage range | 94‑253 VAC |
|---|---|
| Input frequency | 47‑63 Hz |
| Power factor | >0.97 |
| Efficiency (typical) | 75 % |
| Safety standards | EN60950, IEC 950, UL1950, cUL |
| Case material | Steel and aluminium cassette |
| Available outputs | 5 V/16 A, 12 V/6.7 A, 15 V/5.3 A, 24 V/3.3 A |
The VP80 series accepts an input voltage from 94 VAC to 253 VAC.
It complies with the Low Voltage Directive (EN‑60950), IEC 950, UL‑1950 and cUL certifications.
Yes, the unit features active PFC with a power factor greater than 0.97.
Standard outputs are 5 V, 12 V, 15 V and 24 V with current ratings up to 16 A.
