The AD-Q50P200 switching power supply specification lists input/output parameters, safety certifications, reliability tests and component details.
This document provides the technical specification for the AD‑Q50P200 switching power supply manufactured by UME Electronics. It includes the product’s electrical characteristics, safety standards, test procedures, mechanical drawings, and a full bill of materials.
The specification also records the customer approval process, environmental requirements, and packaging details, ensuring the product meets both regulatory and customer expectations. This manual is written in Chinese.
| Rated Input Voltage | 100‑240 Vac |
|---|---|
| Rated Input Frequency | 50/60 Hz |
| Rated Input Current | 0.2 A |
| No‑Load Input Current | ≤20 mA |
| No‑Load Input Power | 0.3 W max |
| Rated DC Output Voltage | 5.0 V (4.75‑5.25 V range) |
| Rated Load Current | 2.0 A |
| Line Regulation | ±1 % (load) / ±5 % (input) |
| Over‑Current Protection | Activates at 110‑200 % of rated output |
The power supply provides a regulated 5 V DC output, with a tolerance of 4.75 V to 5.25 V.
The no‑load input current is limited to 20 mA or less.
The product has an 18‑month limited warranty from the date code.
