User manual for the CoolDrive RC series servo drives, covering safety, installation, wiring, configuration and maintenance.
This manual provides safety information, mechanical and electrical installation instructions, basic commissioning steps, and maintenance guidance for the CoolDrive RC series servo drives. It is intended for system designers, installers, commissioning engineers and maintenance personnel.
The document includes detailed wiring diagrams, connector pin assignments, parameter settings, communication object dictionaries, and troubleshooting advice, helping users set up and operate the drives safely and efficiently. This manual is written in Chinese.
| Encoder interface rated output voltage | 5.0 V |
|---|---|
| Encoder interface maximum output current | 200 mA |
| Control power input voltage | DC 24V ±15%/+20% |
| Control power input current (no brake) | 2 A |
| Rated input current | 12 Arms |
| Motor brake connector max output current | 1 A |
The encoder interface provides a rated output voltage of 5.0 V.
The motor brake connector is rated for a maximum output current of 1 A.
