User guide for the Tianjin Aurora Gemini Power Box, detailing installation, battery setup, safety and maintenance.
The Gemini Power Box is a dual‑linear regulator power system designed for high‑performance servos and receivers in RC models. It provides a stable 5.9 V output for servos/receivers and a secondary 5.3 V output for gyroscopes, with independent monitoring of two batteries.
The manual explains the system’s features, wiring, battery‑type configuration, LED status indicators, safety precautions, and warranty information, helping users install and operate the unit safely and efficiently. This manual is written in Chinese.
| 运行电压 | 4.0V 到 9.0V |
|---|---|
| 电源供应 | 两个 5 芯镍镉电池或镍氢电池，两个 2 芯锂电池 7.4V |
| 电流损耗 | 约 30mA |
| 电压降 | 约 0.30V |
| 最大接收机电流 | 2×4A (稳定) |
| 舵机电源电压 | 5.9V |
| 陀螺仪电源电压 | 5.3V |
| 最大恒定电流 | 10A |
| 温度范围 | -10℃ 至 +75℃ |
| 尺寸 | 72×28×14 mm (长×宽×高) |
| 重量 | 32 g (含导线) |
| 感应开关重量 | 12 g |
The product comes with a 24‑month warranty from the date of purchase, covering material defects.
