The TC9000-N1 Tension Controller User Manual provides setup, wiring, and operation instructions for the TC tension controller.
This manual covers safety information, installation steps, and wiring diagrams for the TC9000‑N1 tension controller. It explains how to connect power, signal, and control lines and includes detailed diagrams of the controller’s terminals.
Operational guidance, parameter settings, and performance specifications are described, along with troubleshooting tips and maintenance recommendations. The document also lists the electrical and mechanical specifications of the device.
| Operating voltage | 24VDC |
|---|---|
| Maximum current | 4 A |
| Torque range | 0.5~0.8 Nm |
| Auxiliary power input | DC 24 V 3.5 A |
The controller operates from a 24 VDC supply.
It provides a torque range of 0.5 to 0.8 Nm.
