The Shenyang Haimo CNC hard turning lathe features a 45° inclined bed, servo‑driven X/Y axes, a 22 kW spindle and an 8‑station hydraulic turret for…
Shenyang Haimo CNC Machine Tool Co., Ltd. introduces its CNC hard turning lathe, a machine designed for high‑precision machining of hardened workpieces. The lathe uses a 45° inclined bed, servo motors on both X and Y axes, and a hydraulic 8‑station turret that automatically changes tools without coolant.
Key specifications include a maximum workpiece diameter and length of 600 mm, a 22 kW spindle motor capable of 750 rpm, rapid feed speeds of 18 m/min (X‑axis) and 9 m/min (Z‑axis), and a robust 6500 kg structure. It is suited for processing bearings, gears, brake discs and other automotive components made from HRC60+ hardened materials. This manual is written in Chinese.
| Maximum workpiece diameter | 600 mm |
|---|---|
| Maximum workpiece length | 600 mm |
| Spindle speed | 750 rpm |
| Spindle motor power | 22 kW |
| X‑axis rapid feed speed | 18 m/min |
| Z‑axis rapid feed speed | 9 m/min |
| Turret type | 8‑station hydraulic turret |
| Machine weight | 6500 kg |
| Machine dimensions | 3500 × 2200 × 2200 mm |
The lathe uses a 22 kW spindle motor.
It can machine workpieces up to 600 mm in diameter.
The turret has 8 hydraulic tool stations.
It can machine end faces, internal/external circles, chamfers, radii, and spherical surfaces.
