Featured 沈阳海默 manuals

Shenyang Haimo CNC Hard Turning Lathe Product Leaflet

Product Leaflet 4 pages · 392 KB · ZH

Shenyang Haimo CNC Machine Tool Co., Ltd. introduces its CNC hard turning lathe, a machine designed for high‑precision machining of hardened workpieces. The lathe uses a 45° inclined bed, servo motors on both X and Y axes, and a hydraulic 8‑station turret that automatically changes tools without coolant.

Key specifications include a maximum workpiece diameter and length of 600 mm, a 22 kW spindle motor capable of 750 rpm, rapid feed speeds of 18 m/min (X‑axis) and 9 m/min (Z‑axis), and a robust 6500 kg structure. It is suited for processing bearings, gears, brake discs and other automotive components made from HRC60+ hardened materials. This manual is written in Chinese.

Covers: Company Introduction · Working Principle · Main Structure · Machinable Workpieces · Application Areas · Technical Parameters

Shenyang Haimo CNC Double-End Grinding Machine Product Leaflet

Product Leaflet 4 pages · 428 KB · ZH

Shenyang Haimo CNC Machine Co., Ltd. has over a decade of experience in CNC machine tools and offers a range of grinding machines, including the double‑end grinding machine. The machine features a dual‑workstation table that can grind the upper and lower parallel end faces of a workpiece simultaneously, enabling rough and finish grinding in one pass.

Key features include a high‑rigidity spindle with CBN end‑face grinding wheels, automatic loading/unloading, real‑time monitoring, and a suite of auxiliary systems such as cooling and oil‑mist extraction. Technical specifications provide a maximum workpiece diameter of Φ140 mm, spindle speed up to 1450 rpm, and cycle times of 10‑15 seconds, making it suitable for high‑volume production of precision components. This manual is written in Chinese.

Covers: Company Introduction · Working Principle · Machine Structure · Operation System · System Configuration · Processable Workpieces

Latest 沈阳海默 manuals

• Shenyang Haimo CNC Hard Turning Lathe Product Leaflet

  Product Leaflet 4 pages · 392 KB · ZH

  The Shenyang Haimo CNC hard turning lathe features a 45° inclined bed, servo‑driven X/Y axes, a 22 kW spindle and an 8‑station hydraulic turret for…

• Shenyang Haimo CNC Double-End Grinding Machine Product Leaflet

  Product Leaflet 4 pages · 428 KB · ZH

  The Shenyang Haimo CNC double‑end grinding machine provides high‑precision, high‑efficiency dual‑workstation grinding for automotive and other precision parts.
