The SC400-M1 user manual provides installation, operation, parameter settings, and troubleshooting for the frequency converter.
This manual covers the mechanical and electrical installation steps for the SC400-M1 frequency converter, including wiring diagrams, safety precautions, and connection details. It also explains how to power the unit, select voltage (220 V/380 V) and configure basic operating parameters.
Further sections describe parameter programming, fault diagnosis, and maintenance procedures. Technical data such as power range, frequency limits, and input current are listed, enabling users to set up the converter for various motor applications. This manual is written in Chinese.
| Power range | 0.2 kW – 93 kW |
|---|---|
| Input voltage | 220 V / 380 V |
| Output current (example) | 0.5 A – 600 A |
The converter can be powered from either 220 V or 380 V AC.
It is rated for loads from 0.2 kW up to 93 kW.
