Technical information for the Sauer-Danfoss DP6XX graphical display family, covering features, specifications, installation, and operation.
This document serves as a technical reference tool for engineering and service personnel regarding the DP6XX series of graphical displays. It details common and variant information including general specifications, connector assignments, input/output parameters, environmental ratings, and installation guidelines.
The manual covers the full range of features available in the DP6XX family, such as real-time clock functionality, multiple interface options (CAN, RedCAN, RS-232, USB), and rugged construction designed for mobile applications. It also provides specific naming conventions, pin-out details for various connectors, and ordering information.
| Microprocessor | 32-bit microprocessor |
|---|---|
| Color Display Resolution | 400 x 240 pixels |
| Monochrome Display Resolution | 320 x 240 pixels |
| Operating Voltage | 12 VDC or 24 VDC |
| Keypad Buttons | 14 buttons (8 soft-keys + 6 navigation) |
The DP6XX features CAN, RedCAN™, RS-232, and USB interfaces.
Yes, the DP6XX includes a built-in real-time clock.
Standalone units can be mounted on a post according to VESA standards.
